W
WalliN W
Multi utility house entry for the
installation of supply pipes
WalliN W
Builder Package
Type selection
WalliN W Builder Package - Wall
Fields of application
Multi utility house entry for supply lines (gas, water, electricity, telecommunication) for buildings with basement
Material
PVC housing, sealing inserts, external sealing element with flange seal, end plugs and hose connectors
Properties
Gas- and water pressure-tight up to 1 bar; gas- and odor-tight (high-quality in terms of TA-Air); radon-tight; resistant to methane gas; four-skid seal: exterior sealing of concrete up to 10 bar
DafStB waterproof concrete guideline: stress class 1 + 2, DIN 18533 W1 -E and W2.1 -E
Sizes
DN 200 (199 - 203 mm)
Download
Product Information
Properties
- DVGW approval
- Split end plugs for easy installation
- Torque control nut: Automatic torque without torque wrench
Fields of application
Safe and tight house entry multi utility for supply lines such as gas, water, electricity, and telecommunications for buildings with basements.
Notes
Extension set included
Description
The WalliN W house entry multi utility is ideal for gas- and pressure-tight multiple entries of supply lines for buildings with basements – up to a pressure of 1 bar.
Scope of supply
- Internal sealing element with pre-installed casing pipes incl. protective covers for the installation of supply lines such as gas, water, electricity, telecommunication.
- External sealing element
Extension Set:
- 4x double sleeve DN 75
- 8x sealing rings
Installation Set:
- Sealing Insert - electricity/water: - 2 Pieces
with stepless onion ring technology 26-50 mm
or blind, primary sealing + secondary sealing,
casing pipe end plugs, end plug split, hose connection 80 - Sealing Insert - telecommunication:
clamping range: 5-13 mm, 3x 7-13 mm, 13-21 mm,
primary sealing + secondary sealing,
casing pipe end plugs including, end plug split, hose connection 80 - Sealing Insert - electricity + telecommunication:
clamping range: electricity 25 - 36 mm /
telecommunication 2 x 5 - 10 mm, 3 x 7 - 14 mm,
primary sealing + secondary sealing, casing pipe
end plugs including, end plug, hose connection 80
Optionally available Gas installation sets:
- Schuck DN 25 consisting of primary and secondary sealing as well as gas end plug
- RMA DN 25 consisting of primary and secondary sealing as well as gas end plug
- Voigt DN 25 consisting of primary and secondary sealing as well as gas end plug
- Voigt DN 32 consisting of primary and secondary sealing as well as gas end plug
Technical Information
Certificates
To offer our customers the best possible quality and service, we are organized according to DIN EN ISO 9001:2015 and have this continuously checked and certified.
CERTIFICATE ISO 9001:2015
This certification documents our conformity of the quality management system
AEO-CERTIFICATE
Authorized Economic Operator "AEOC (customs simplification)"
Builder Package
- DVGW-certified according to VP 601: overall system is gas- and water pressure tight up to 1 bar!
- Radon tightness IAF tested
- Methane gas resistant
- DafStB waterproof concrete guideline: stress class 1 + 2, DIN 18533 W1 -E and W2.1 -E
